Capacities of TNTmips Free, Basic, and Pro

TNTmips Free — Learning Tools

TNTmips Free is a version of TNTmips Pro designed for free student use. TNTmips free is not a demo; it is a fully featured geospatial analysis software package. TNTmips Free is exactly the same program as TNTmips Pro except that the license to use it free-of-charge determines the size, number, and complexity of geodata layers you can use in your project and omits some advanced features.

TNTmips Basic — Small Projects

TNTmips Basic is a low-cost upgrade of TNTmips Free with increased capabilities to enable professional geospatial analysis projects of a larger size. Your TNTmips Free can be upgraded to TNTmips Basic at any time using your credit card via PayPal.

Additional features are also activated in TNTmips Basic. You can automatically view any combination of your georeferenced geodata (images, shape, CAD, LIDAR, …) anywhere in the world in full 3D color using your 3D monitor or 3D TV or in anaglyph. Through your Internet connection you can also view any location in the world in 3D using imagery published at microimages.com and by WMS or ARC. Converting the content of your 2D view to a 3D view can use your local DEM or automatically use the global elevation data published at microimages.com.

TNTmips Pro — Global Capabilities

TNTmips Pro is the most comprehensive professional geospatial analysis package available. It is priced much lower than competitive products even when you purchase their entry level versions that subsequently require the purchase of many additional extensions and modules. All of TNTmips Pro's comprehensive geospatial analysis features are included in a single price.

TNTmips Basic 2012 Prices

single units are only available via MicroImages online store
payment by PayPal using a credit card or by using a prepaid token, no purchase orders or proformas

1 computer-locked license, immediate online authorization US$200

5 computer-locked licenses (i.e. codes) to activate online on each computer US$900
This is the minimum quantity that can be ordered offline by invoice, credit card, or debit card. Please request quote for larger quantities.

5 key-locked portable licenses, each uses its own portable USB key
US$1500 including 5 keys
add US$100 for handling and shipping by DHL

10 seat network license, uses a single floating license USB key
US$3000 including 1 key
add US$100 for handling and shipping via DHL

Choose license level based on the project size,
data complexity, and advanced features you need.

Geodata usable in TNTmips:	Free	Basic	Pro
• Cells in each raster or image	1,000,000	4,000,000	>terabytes
• Topological vector elements in each layer
points	1,500	3,000	unlimited¹
lines	1,500	3,000	unlimited
polygons	500	1,000	unlimited
labels	1,500	3,000	unlimited
• CAD elements in each layer
elements	500	1,000	unlimited
blocks	5	5	unlimited
• Shape elements in each layer	500	1,000	unlimited
• LIDAR points in each layer	500,000	2,000,000	unlimited
• Database records each table	1,500	3,000	unlimited
• Each view
Color 3D (i.e., in stereo)	no	yes	yes
Bing Maps layers	no	no	yes²
number open at same time	2	2	unlimited
groups of layers in view	10	10	unlimited
layers in each group	20	20	unlimited
total number of layers	50	50	unlimited
raster tilesets (web or local)	no	yes	yes
render layers to tileset	no	no	yes³
• Feature Mapping
map classes	9	9	unlimited
total number of features	100	100	unlimited
• Web Publishing⁴
create and manage tilesets	no	no	yes
mashup tilesets	no	no	yes
• Production Operations
Use SML scripting language	no	yes⁵	yes
Job Processing⁶	no	no	yes
• Size of Prints	A3/12x17	A3/12x17	unlimited³
• Save table view for external use	no	yes	yes

¹ Unlimited means that there is no limit on the number of elements in the layer that can be created or used in TNTmips Pro, however, limits may be imposed by your hardware, other software, or operating system.

² Each TNTmips Pro comes with a license purchased by MicroImages from Microsoft to use the Bing Maps image and road layers in every TNT view. This license is valid until the release of TNTmips Pro in January 2013.

³ A P15 option is required to print or render a layout directly from a TNT view to a size greater than A3/12x17. This is the only option available for TNTmips.

⁴ TNTmips Pro can prepare and assemble raster, vector, CAD, shape, DEM, tilesets (raster, KML, and SVG), and other geodata types for viewing and other uses in Google Maps, Bing Maps, Google Earth, OpenLayers, and World Wind.

⁵ SML is MicroImages' unique and powerful geospatial scripting language built into the TNT products. TNTmips Basic can use SML to structure queries, add tools to views, and add internal macro processing methods. Only TNTmips Pro can be used to create "stand alone" SML scripts that can be distributed and run as separate processes under any Pro license to TNTmips, TNTedit, or TNTview.

⁶ Job Processing = TNTmips Pro will simultaneously execute the same or different independent analysis processes or tasks on each of your processors to greatly improve throughput.
